Description

High-efficiency LED underwater luminaire designed for illumination of medium and large swimming pools, fountains, water bodies, waterfalls, and decorative water features. The fixture features a compact stainless-steel housing with precision optical lenses and high-performance LEDs, delivering uniform underwater illumination with excellent energy efficiency and long service life.

Manufactured using marine-grade stainless steel and fully sealed construction, the luminaire is suitable for continuous underwater operation in chlorinated pools, fountains, and landscape water applications.

• LED WATT :12W/18W/24W
•  Single Color (CCT) : 2750k , 2950k ,4000k, 6000k , Multi color : RGB / DMX
•  Lumen / watt : 110 lm - 140 lm
• Available Beam Angle : 15°/25°/30°/45°/60°
•  Input Voltage : 12V / 24V DC
•  Dimmable : Dali / RGB - DMX-On Request
•  Dimensions : 110 mm , H 30 mm
•  IP ( Ingress Protection ) : IP 68
•  Driver : Remote : IP 67

Product Details

• Specifications

  Performance

  POOLZ MIDI	CCT	CRI	Lumen P/W
  arle / w/p/ m6	3000K/ 4000K/6000K/RGB/RGBWW	80	85lm/W
  arle / w/p/ m6	3000K/ 4000K/6000K/RGB/RGBWW	80	85lm/W

• Application

  • Swimming Pools
  • Hotel & Resort Pools
  • Decorative Fountains
  • Water Features
  • Waterfalls
  • Reflection Pools
  • Landscape Water Bodies
  • Public Water Installations
  • Architectural Water Effects
