Description

Model : arle / linw / 03A

• Compact & Minimilist linear surface mounted luminaire designed for wall,ceiling & floor mount application.
• Ideal light distribution serves both wall washing & wall grazing applications.
• Luminaire made up of NESS STELL / Alluminium STAI Heat Singh and flush end caps with silicone gasket.
• Surface / Recessed / Suspended mounting options available.
• Clear toughened glass.
• Equipped to take multiple optics for varied wall grazing & spot light distribution.
• Optical compartment closed at the top by a 3mm thick toughened
  glass screen secured with silicone.
  LED WATT : 06W /12W / 36W / 54W
   Single Color (CCT) : 2750k , 2950k , 4000k, 6000k
•  Multi color : RGB
   Lumen / watt : 110 lm - 140 lm
  Dimensions : L 300mm x W 80mm / L500mm x W 80mm / L 1000mm x W 80mm
   IP ( Ingress Protection ) : IP 66 / 67
   Outdoor Casing :SS 304 / SS 316
   Driver : Built In / Remote

Product Details

• Specifications

  Performance

  LINEUP STEEL	CCT	CRI	Lumen P/W
  LINEUP STEEL	2750k	80	110 lm - 140 lm

• Application

  Building Facade,
  Textured surfaces,
  Building mounted focal points,Bridges,Archaeological
  monuments,etc..
  Product Benefits
  • Visual comfort with maximum energy saving.
  • Minimilist design with optimum performance.
  • Quick & simple installation.
  • Flexible deployment options with a wide spectrum of applications.
