Description

Model : arle / linw / 03

• Compact & Minimilist linear surface mounted luminaire designed for wall,ceiling & floor mount application.
•  Ideal light distribution serves both wall washing & wall grazing applications.
• Luminaire made up of extruded aluminium alloy and flush end caps with silicone gasket.
•  Clear toughened glass.
• Mounting bracket with an adjustable feature from 0°-45° facilitate proper aiming of the luminaire at desired angle.
• Wall,ceiling and floor mount options with adjustable brackets.
• Luminaries supplied with one metre cable length and a IP67 connector.
• Silicone gasket for moisture protection
  LED WATT : 36W
• Single Color (CCT) : 2750k , 2950k , 4000k, 6000k
•  Multi color : RGB/RGBWW/RGBW
•  Lumen / watt : 110 lm - 140 lm
  Dimensions : L 500mm x W 50mm / L1000mm x W 50mm
•  IP ( Ingress Protection ) : IP 66 / 67
• Driver : Built In / Remote

Product Details

• Specifications

  Performance

  STANDARD VISIOR	CCT	CRI	Lumen P/W
  STANDARD VISIOR	2750k , 2950k , 4000k, 6500k, RGB/RGBWW/ RGBWH	80	110 lm - 140 lm

• Application

  • Building Facade,Textured surfaces,Building mounted focal points,Bridges,Archaeological monuments,etc..

    Product Benefits
  •  Visual comfort with maximum energy saving.
  •  Minimilist design with optimum performance.
  •  Quick & simple installation.
  •  Flexible deployment options with a wide spectrum of applications.
