Description

Model : ar / linw / 01

• Compact & Minimilist linear surface mounted luminaire designed for
  wall,ceiling & floor mount application.
• Ideal light distribution serves both wall washing & wall grazing
  applications.
• Luminaire made up of extruded aluminium alloy and flush end caps with
  silicone gasket.
• Clear toughened glass
• LED WATT : 18W / 36W / 54W
•  Single Color (CCT) : 2750k , 2950k,, 4000k, 6000k
•  Multi color : RGB
•  Lumen / watt : 110 lm - 140 lm
• LED Make : Edision / CREE
•  Available Beam Angle : 15°/25°/30°/45°/60°(Asymetric lense)
•  Input Voltage : 220V AC
•  Dimensions : L 300mm x W 50mm / L 500mm x W 50mm / L 1000mm xW 50mm
•  IP ( Ingress Protection ) : IP 66 / 67
•  Outdoor Casing : 6063 Aluminium Alloy
•  Driver : Built In / Remote

Product Details

• Specifications

  Performance

  STANDARD LINE 2	CCT	CRI	Lumen P/W
  STANDARD LINE 2	2750k , 2950k , 4000k, 6500k	80	110 lm - 140 lm

• Application

  Building Facade,
  Textured surfaces,
  Building mounted focal points,Bridges,Archaeological
  monuments,etc..
