Description

Model : arle/ stp/r6

• A perfect combination of sleek and aesthetic fixtures designed to provide uniform illumination for low mounting heights where guidance and security lighting is required. Sustainable LED technology offers durability and optimal light output with low power consumption.
•  Silicone gasket
•  ABS plastic installation housing for preparing the recess opening in wall / stairs for flush mounting.
•  Luminaire made of pressure die cast aluminium alloy of high corrosion resistance and non corrosive A2 stainless steel fasteners
• Hybrid optics with lens & reflector combination for higher efficiency,lower optical losses with optimum glare suppression.
  LED WATT : 04W/07W/12W
   Single Color (CCT) : 2750k , 2950k , 4000k, 6000k
•  Multi color : RGB
•  Lumen / watt : 110 lm - 140 lm
•  Single Color (CCT) : 2750k , 2950k ,4000k, 6000k
•  Multi color : RGB
•  Lumen / watt : 110 lm - 140 lm
• LED Type : SMD
   LED Make: OSRAM
   Beam Angle : 120°
• Dimensions : 200mmx90mmx30mm
   IP ( Ingress Protection ) : IP 66 / 67
   Outdoor Casing : Die Cast Alluminium
   Driver : Built In / Remote

Product Details

• Specifications

  Performance

  LINEAR STEP	CCT	CRI	Lumen P/W
  LINEAR STEP	2750k	80	110 lm - 140 lm
  	2950k	80	110 lm - 140 lm
  	4000k	80	110 lm - 140 lm

• Application

  Staircase,Patios,Walkways,Passages,Porches,Entrance & Exits for both Interior & Exterior applications.
