Description

Model : arle/ stp/r5

• Asymmetrical recessed mount floor washer with a wide beam for glare free illumination of pathways, entrances etc.Sustainable LED technology offers durability and optimal light
  output with lower power consumption.
•  Luminaire made of pressure die cast aluminium alloy of high corrosion resistance and non corrosive A2 stainless steel fasteners.
• Mounting bracket to facilitate proper aiming of the luminaire at desired angle during installatiLED LED WATT : 01W/03W
• Single Color (CCT) : 2750k , 2950k , 4000k, 6000k
•  Multi color : RGB
•  Lumen / watt : 110 lm - 140 lm
•  LED Type : SMD
•  LED Make: OSRAM
• Dimensions : 85mmx25mm
   IP ( Ingress Protection ) : IP 66 / 67
   Outdoor Casing : Die Cast Alluminium
   Driver : Built In / Remote
  Product Benefits
• High visual comfort
•  High visual comfort
•  A sleek and minimalist shape provides distinctive
• lighting effects for walkway architecture

Product Details

• Specifications

  Performance

  STEP MINI	CCT	CRI	Lumen P/W
  STEP MINI	2750k , 2950k , 4000k, 6500k, RGB,RGBWW, RGBWH	80	110 lm - 140 lm

• Application

  Staircase,Patios,Walkways,Passages,Porches,Entrance & Exits for both Interior & Exterior applications.
