Description

Model : arle/ stp/r1

• Step Vertical a perfect combination of sleek and aesthetic fixtures designed to provide uniform  illumination for low mounting heights where guidance and security lighting is required Sustainable LED technology offers durability and optimal light output with low power  consumption
•  Silicone gasket
•  ABS plastic installation housing for preparing the recess opening in wall / stairs for flush mounting.
• Non yellowing UV stabilized clear acrylic diffuser Luminaire made of pressure die cast aluminium alloy of high corrosion resistance and non corrosive A2 stainless steel fasteners.
  LED WATT : 03W/06W
• .Single Color (CCT) : 2750k , 2950k , 4000k, 6000k
•  Multi color : RGB
•  Lumen / watt : 110 lm - 140 lm
• LED Type : SMD
   LED Make: OSRAM
   Beam Angle :: 15°/30°/45°(Asymetric lense)
   Input Voltage : 220V AC
   Dimensions : 165mmx65mm
   IP ( Ingress Protection ) : IP 66 / 67
   Outdoor Casing : Die Cast Alluminium
   Driver : Built In / Remote

Product Details

• Specifications

  Performance

  STEP VERTICAL	CCT	CRI	Lumen P/W
  STEP VERTICAL	2750k , 2950k , 4000k, 6500k, RGB,RGBWW, RGBWH	80	110 lm - 140 lm

• Application

  Staircase,Patios,Walkways,Passages,Porches,Entrance & Exits for both Interior & Exterior applications
