Description

Model : arle/ stp/r13

• Asymmetrical surface mount SQ floor washer with a wide beam for glare free illumination of pathways, entrances etc.Sustainable LED technology offers durability and optimal light output with lower power consumption
•  Silicone gasket
•  Die cast aluminium installation housing for surface mounting on wall.
• Luminaire made of pressure die cast aluminium alloy of high corrosion resistance and non corrosive A2 stainless steel fasteners.
  LED WATT : 04W
   Single Color (CCT) : 2750k , 2950k , 4000k, 6000k
   Multi color : RGB
   Lumen / watt : 110 lm - 140 lm
• LED Type : SMD
   LED Make: OSRAM
   Beam Angle : 45°/60°
   Input Voltage : 220V AC
  • Dimensions : 230mmx85mm
     IP ( Ingress Protection ) : IP 66 / 67
    Available Finish
     Pure polyester powder coat
     Graphite grey
     Anthracite grey
     Jet black

Product Details

• Specifications

  Performance

  STEP SURFACE SQ	CCT	CRI	Lumen P/W
  STEP SURFACE SQ	2750k , 2950k , 4000k, 6500k, RGB,RGBWW, RGBWH	80	110 lm - 140 lm

• Application

  Staircase,Patios,Walkways,Passages,Porches,Entrance & Exits for both Interior & Exterior applications.
